- Nama Produk
INDIKATOR T 18 MERK SAYAKI
- Brand
INDIKATOR T 18 MERK SAYAKI
INTRODUCTION
Sonic T18 weighing indicator adopts high anti-jamming single-chip microprocessor and high precision ∑ – ∆ A/D conversion technology, wildly applied in platform scale, platform balance and other weighing applications.
Features
- Kg/lb one key switch, total, upper and lower limit, animal scale, RS232 communication
| Technical Parameter |
| Accuracy class: III, n=3000 |
| A/D Conversion Mode: Adopts ∑ – ∆ Technology, 10 Times per Second |
| Input Sensitivity ≥ 1.5uV/e |
| Excitation: DC 5V |
| Input Signal: -16mV ~ 18mV |
| Load Cell connection mode: 6 Wire Connection (Long Wire Auto Compensation) |
| Division 1/2/5/10/20/50 Optional |
| Power supply: AC 85 ~ 245V, 50Hz ~ 60Hz; Built in battery DC 6V/4AH |
| Working temperature: 0 ~ 40°C; Working humidity ≤90%RH |
| Working temperature: -10°C ~ 40°C; Humidity 10% ~ 85%, No condensation |
| Storing temperature: -30°C ~ 60°C, Humidity 10% ~ 70%, No condensation |
